Parker F3 type (PTFE) with a piston rod or guide strips

1. INTRODUCTION

F3 type guide with hydraulic cylinders.
advantage:
● can be of any length provided.
● Since the insertion of bronze powder PTFE material, this product has a high load, low wear, low friction characteristics.
● At low speeds and high radial load, no creeping phenomenon.
● Simple groove design to avoid contact with the sliding surface of the metal.
● can supply a variety of customer needs.

2. Materials

    Standard: Polon ® 052, PTFE + 40% copper
              For alloy materials, light metals and high-grade carbon steel tanks is recommended Polon33 (PTFE + 25% carbon).

3. Application:

   Working temperature: -100 to + 200 ° C

  Surface speed: ≤5m / s

If the special requirements (pressure, temperature, speed, etc.), please consult our service department in order to recommend the right materials and structures
